Bolt Energy 51V 60Ah EZGO TXT & RXV – Plug & Play Samsung Gen 1 Lithium Replacement (Copy)

The Bolt Energy 51.2V 60Ah lithium battery for EZGO TXT & RXV with Gen 1 Samsung Factory Lithium is the most complete drop-in lithium upgrade available — 3,072Wh of LiFePO4 power, a waterproof charger, Bluetooth monitoring, and an industry-leading 12-year transferable warranty, all in one kit. If you've been searching for a bolt lithium EZGO TXT upgrade, this is it.

Why Choose Bolt Lithium for Your EZGO TXT?

• ✅ 12-Year Transferable Warranty — industry-leading coverage that transfers to the next owner if you sell your cart
• ✅ LiFePO4 Chemistry — safer, longer-lasting, and more stable than lead-acid or standard lithium
• ✅ Bluetooth Monitoring — track state of charge in real time from your phone
• ✅ IP66-Rated Enclosure — weather-resistant powder-coated steel case
• ✅ Plug-and-Play Kit — everything included for a complete installation
• ✅ <3% Monthly Self-Discharge — holds charge during off-season storage

Professional Kit Includes:

• 51.2V 60Ah Battery
• Bluetooth receiver
• Smart SOC (State of charge meter)
• Owner’s manual
• Six 3/8 battery ring terminal connectors
• Ten 10" tie straps
• Bolt Energy USA stickers
• Waterproof high-speed charger
• Mounting brackets, Nuts, and bolts
• AC Hardwire PORT
• AC hardwire DECO Cover plates
• 30-amp reducer
• Two 40" 2AWG premium installation cables
• 400A solenoid
• Lead battery removal strap
• 15ft 12 AWG Green lighted extension cord
• Samsung Gen1 Can Adapter

Electrical Specifications:

• Nominal Voltage: 51.2V
• Working Voltage: 43.2 – 58.4V
• Recommended Voltage: 48.0V – 57.0V
• Nominal Capacity: 105Ah
• Energy: 5,376Wh
• Capacity at 25A: 252 min
• Efficiency: 0.99
• Self-Discharge: <3% per month

Discharge Specifications:

• Nominal Voltage: 51.2V
• Working Voltage: 43.2 – 58.4V
• Recommended Voltage: 48.0V – 57.0V
• Nominal Capacity: 60Ah
• Energy: 5,376Wh
• Capacity at 25A: 252 min
• Efficiency: 0.99
• Self-Discharge: <3% per Month


Charge Specifications:

• Recommended Charge Current: 5 – 52A
• Maximum Input Current: 350A
• Charge Current Cut-Off: 375A
• BMS Charge Voltage Cut-Off: 58.5V
• Reconnect Voltage: <58.5V
• Charging Temperature Range: 34°F to 140°F (0°C to 60°C)

Mechanical Specifications:

• Dimensions (L x W x H): 12.8" x 12.01" x 10.28"
• Weight: 72.75lbs (45.7kg)
• Terminal Type: M8*1.5*25mm
• Cell Configuration: 1P16S
• Case Material: Powder Coated Steel
• Enclosure Protection: Designed with IP66 Standard
• Cell Type – Chemistry: Prismatic- LiFePO4


Communication:

• Bluetooth receiver for mobile monitoring
• CAN port for battery diagnostics

Frequently Asked Questions

Is this Bolt lithium battery compatible with my EZGO TXT?

Yes — this Bolt Energy 51.2V 105Ah kit is designed specifically as a drop-in lithium upgrade for the EZGO TXT and RXV with Factory Samsung Gen 1 Lithium. Replace and drive away.

What does the 12-year transferable warranty cover?

The Bolt Energy 12-year transferable warranty covers defects in materials and workmanship for the full 12 years — and it transfers to the next owner if you sell your golf cart, making it a genuine value-add at resale.

How long does the Bolt lithium battery last in an EZGO TXT?

Bolt Energy lithium batteries are rated for 3,000–5,000 charge cycles, which translates to approximately 10–15 years of typical use. The 12-year transferable warranty backs this up with industry-leading coverage.

Do I need a new charger for my EZGO TXT when switching to lithium?

Yes — lithium batteries require a lithium-specific charger. This kit includes a waterproof high-speed charger designed specifically for the Bolt 51.2V battery, so you don't need to purchase anything separately.

How much range will I get after installing the Bolt lithium battery in my EZGO TXT?

Most EZGO TXT owners report up to 40 miles per charge, thanks to top-tier Grade A lithium cells.

How hard is it to install a Bolt lithium battery in an EZGO TXT?

Installation difficulty is moderate — most experienced DIYers complete it in 2–4 hours. The kit includes all necessary hardware and an owner's manual. Professional installation is recommended for those unfamiliar with golf cart electrical systems.

Will the Bolt lithium battery fit in my EZGO TXT battery compartment?

Yes — the "Square" form factor (12.8" x 12.01" x 10.28") is designed to fit the EZGO TXT battery tray. Mounting brackets are included to secure the unit properly.
